AMT 3937-D5 2" Cast Iron Self-Priming Engine Driven Trash Pump (Hatz Diesel 1B30, Viton®/Silicon Carbide Seal)
AMT 3937-D5 2" Cast Iron Self-Priming Engine Driven Trash Pump (Hatz Diesel 1B30, Viton®/Silicon Carbide Seal)
SKU:3937-D5
Couldn't load pickup availability
AMT 3937-D5 2" Cast Iron Self-Priming Engine Driven Trash Pump is designed, manufactured and tested in the USA. This model is equipped with a Hatz Diesel 1B30 engine and easy clean-out design eliminating the need to remove any fittings or hoses to remove debris. A strong cast iron body increases durability while the Viton®/Silicon Carbide mechanical seal prolongs the longevity of the internal parts. AMT Pump Company is a subsidiary of The Gorman-Rupp Company.
Specifications:
-
Pump Body: Cast Iron
-
Mechanical Seal: Viton®/Silicon Carbide Seal
- Maximum Flow Rate: 185 gpm - See Performance Chart
-
Ports: 2" NPT
- Engine: Hatz Diesel 1B30 - 12V DC Electric Start (Battery Not Included)
- Weight: 175 lbs
AMT Cast Iron Engine Driven Trash pumps are designed for applications which require high flow efficiency, solids handling capability and abrasion resistance. This series of pumps are also good for chemical spraying, handling and processing. These pumps are constructed of heavy duty CNC machined cast iron components featuring removable/replaceable cast iron volute and impeller. Simple four bolt clean out design permits easy removal of trash and debris without disconnecting hoses. Pumps are available with gasoline overhead valve or diesel engines from various engine manufacturers.
Series Features:
-
Cast Iron Construction
-
Viton® /Silicon Carbide Mechanical Seal
-
2˝ NPT Port Sizes
-
Self-Priming up to 20 Feet with Built-In Viton® Check Valve
-
Engine Options: Honda or Hatz Diesel
-
Heavy Duty Steel Roll Frame Included
-
Maximum Solids Handling up to 1˝ Diameter
-
Maximum Head up to 105 Ft.
-
Maximum Flow up to 185 GPM
-
Optional Wheel Kit Available
- Solids Handling and Dirty Water Design
- Maximum Solids Handling up to 1˝ Diameter
- (2) NPT Pipe Nipples & 2" Street Elbow Included
- Stainless Steel Shaft Sleeve
- Steel Suction Strainer Included
- Cast Iron Replaceable Volute/Wearplate and Impeller
- Maximum Temperature 180° F
- Maximum Working Pressure 75 PSI
