Goulds VTX1012 VTX Series Vortex Submersible Sewage Pump (1 HP, Single Phase, 230V)

The Goulds VTX1012 1 HP VTX Series Vortex Submersible Sewage Pump can handle solids up to 2" in size helping minimize clogging which in turn decreases downtime. Designed and manufactured by Goulds Water Technology, a trusted name in the industry for quality and reliability. Please contact a member of our sales or service team for assistance in selecting the correct pump for your needs!

Pump Casing Material:  Cast Iron

Voltage:  230V

Motor:  1 HP, Single Phase

Impeller Material:  3.75", Cast Iron

Discharge:  2" NPT

Maximum Flow Rate:  172 gpm - See Performance Chart

Maximum Head:  48'

Cord Length:  20'

Temperature:  104°F (40°C) continuous, 140°F (60°C) intermittent. Class B Insulation.

Duty Cycle:  Continuous

RPM:  3500

Frequency:  60 Hz

Maximum Amps:  9.5

Locked Rotor Amps:  45.2

KVA Code:  B

Full Load Efficiency %:  78

Resistance Main (White - Black):  1.2 - 1.3

Resistance Phase (White - Brown):  3.2 - 4.6

Field Serviceable: A built in dry cap makes it easy to replace the capacitor in the field.

Resists Clogging: A vortex impeller handles stringy material and resists clogging better than a traditional two-vane impeller.

Built to Last: A premium silicon carbide silicon carbide seal comes standard for superior abrasive resistance.

Like any good vortex pump, it offers plenty of benefits to industry:

• It can handle solids up to 2” in size.
• Solids don’t touch the vanes.
• The design minimizes clogging.
• It easily passes stringy materials.

But unlike other vortex pumps, the GWT Vortex is built upon Goulds Water Technology’s reputation for reliability. That means it’s built tougher, it performs better, and it runs longer than your ordinary vortex pump.

Features:

• Impeller: Cast iron, multivane, vortex style
• Casing: Cast iron volute for maximum efficiency. Designed for easy installation on A10-20 slide rail or base elbow rail systems.
• Mechanical Seal: SILICON CARBIDE VS. SILICON CARBIDE sealing faces for superior abrasive resistance, stainless steel metal parts, BUNA-N elastomers.
• Shaft: Corrosion-resistant, 300 series stainless steel. Threaded design. Locknut on all models to guard against component damage on accidental reverse rotation.
• Fasteners: 300 series stainless steel
• Capable of running dry without damage to components.
• Designed for continuous operation when fully submerged.


Series Specifications:

• Impeller: Cast iron, multi-vane, vortex style
• Casing: Cast iron volute for maximum efficiency
• Mechanical Seal: Premium silicon carbide mechanical seal
• Shaft: Corrosion-resistant, 300 series stainless steel with a threaded design
• Fasteners: 300 series stainless steel Capacitor Compartment Oil free Solids
• Handling Capabilities: 2” maximum
• Capacities Up to 208 GPM
• Total Heads Up to 66 feet TDH
• Discharge Size: 2” NPT threaded as standard
• Temperature 104°F (40°C) continuous, 140°F (60°C) intermittent, Class B insulation
• A complete family of pumps ranging from ½ to 2 HP
• PSC motors for maximum starting torque
• Built-in thermal overload protection with automatic reset
• Oil-filled motor for constant heat dissipation and cool operation
• SJTOW severe duty oil and water resistant power cords, 20’ length
• NEMA three prong grounding plugs
• A complete family of pumps ranging from ½ to 2 HP
• PSC motors for maximum starting torque
• Built-in thermal overload protection with automatic reset
• Oil-filled motor for constant heat dissipation and cool operation
• SJTOW severe duty oil and water resistant power cords, 20’ length
• NEMA three prong grounding plugs

Motor Specifications:

• Fully submerged in high grade turbine oil for lubrication and efficient heat transfer. All ratings are within the working limits of the motor.
• Class B insulation on 1 ⁄2, 3/4, 1, 11 ⁄2, 2 HP models.
• Single phase (60 Hz): PSC motors for improved reliability with no starting switches and low start & running current.

Applications:

Specifically designed for the following uses:

• Homes • Water transfer • Sewage systems • Light industrial • Dewatering/Effluent • Commercial applications

Anywhere waste or drainage must be disposed of quickly, quietly and efficiently.
