AMT 2D3-X2-3P Self-Priming Centrifugal Pump (2 HP, 230/460V, 3 Phase, 2" NPT, Explosion Proof)

The AMT 2D3-X2-3P is a 2 HP, three-phase self-priming centrifugal pump designed for industrial applications requiring an explosion-proof motor. Its rugged gray cast-iron construction, 2" NPT suction and discharge connections, and Viton® sealing system make it suitable for demanding liquid-transfer installations where compatible materials and hazardous-duty electrical equipment are required.

The 3450 RPM motor operates on 230/460V three-phase power. The pump self-primes to 20 feet and handles solids up to 3/8" diameter.

Features:

• 2 HP Motor
• 230/460V
• Three Phase
• Explosion-Proof Motor
• 3450 RPM
• Cast Iron Construction
• Viton® Seal, Carbon & Ni-Resist Faces
• 2" NPT Suction
• 2" NPT Discharge
• Self-Priming to 20 Ft.
• Up to 128 GPM Series Maximum Flow
• Up to 72 Ft. Series Maximum Head
• 31 PSI Max Operating Pressure
• 160°F Max Temperature
• 3/8" Solids Handling

Specifications:

• Manufacturer: AMT Pump Company
• Model: 02D3-X2-3P
• HP: 2 HP
• Voltage: 230/460V
• Phase: Three Phase
• Speed: 3450 RPM
• Suction: 2" NPT
• Discharge: 2" NPT
• Construction: Gray Cast Iron
• Seal: Viton® / Carbon / Ni-Resist
• Motor Enclosure: Explosion Proof
• Max Priming Lift: 20 Ft.
•  Max Operating Pressure: 31 PSI
• Max Temperature: 160°F
• Max Solids: 3/8"
• Shipping Weight: 101 lbs.
