AMT 388J-98 Stainless Steel Centrifugal Pump (1-1/2 HP, Single Phase, 1-1/2" NPT, 115/230V)

The AMT 388J-98 is a 1-1/2 HP stainless steel centrifugal pump designed for gravity-fed chemical processing, dirty water transfer, and industrial liquid transfer applications. The pump features a self-cleaning stainless steel impeller for handling solids up to 1/8" diameter, a Buna-N mechanical seal and O-ring, and a TEFC single-phase motor. Its pull-from-rear design simplifies maintenance without requiring removal of connected piping. This pump is not self-priming and requires flooded suction.

Features:

• Stainless steel construction
• Self-cleaning stainless steel impeller
• Handles solids up to 1/8"
• Buna-N mechanical seal and O-ring
• TEFC single-phase motor
• Pull-from-rear design
• 1-1/2" NPT suction and discharge
• 75 PSI maximum working pressure
• 180°F maximum liquid temperature

Applications:
Chemical processing, dirty water transfer, industrial liquid transfer, process water, water circulation, equipment cooling, commercial applications, general service pumping.

.Specifications:

• 1-1/2 HP
• Single Phase
• Stainless Steel Construction
• TEFC Motor
• Voltage: 115/230 VAC, 60 Hz
• Full Load Amps: 16/8 A
• 1-1/2" NPT Female Suction
• 1-1/2" NPT Female Discharge
• Maximum Flow: 136 GPM
• Maximum Head: 68 Ft.
• Maximum Working Pressure: 75 PSI
• Maximum Liquid Temperature: 180°F
• Maximum Solids Handling: 1/8" Diameter
• Dimensions: 14.2" L × 9.1" W × 8.7" H
• Shipping Weight: 51 lbs.
• Non-Self-Priming — Flooded Suction Required
