Flomatic 9614410 46 10" Flanged Cast-Iron Strainer (316 Stainless-Steel Screen & Flange)

The Flomatic 9614410 Model 46 10" flanged strainer is designed for larger water system piping where robust debris protection is required. This model features an epoxy-coated cast-iron body with an ANSI 125 flanged connection and a removable 316 stainless-steel screen and flange, providing durability and corrosion resistance in demanding applications.

Specifications:

Max Pressure: ANSI 125

Max Temperature: 180°F (82°C)

Body: Epoxy-coated cast iron

Screen: 316 stainless-steel

Flange: 316 stainless-steel

Open Area: Approximately 58%

Connection: 10" ANSI 125# flanged

Weight: 37 lbs

Operation: Installed inline, the Model 46 flanged strainer directs flow through the internal stainless-steel screen to capture debris before it can reach downstream pumps, meters, or control valves. The flanged design allows secure installation in ANSI-rated piping systems.

Construction: The epoxy-coated cast-iron body provides strength for large-diameter piping, while the removable 316 stainless-steel screen and flange offer excellent corrosion resistance and long service life.

Flomatic Engineering: Flomatic strainers are manufactured with an emphasis on durability, consistent quality, and dependable performance in water and pumping systems.

Applications: Municipal water distribution, industrial process piping, cooling water systems, and commercial installations where a heavy-duty flanged strainer is required to protect equipment from debris.
