Goulds AGS1012 AGS Series Axial Grinder Pump (1 HP, Single Phase, 230V, 3500 RPM, Manual)

The Goulds AGS1012 AGS Series Axial Grinder Pump is backed by 170 years of American ingenuity - engineered, built and tested in the USA. If your current sewage pump is experiencing clogging issues the AGS grinder pump can solve your problems. Heavy duty cast iron body and stainless steel cutter make this the maintenance free grinder pump of choice for both residential and light commercial needs.

**Picture is stock photo - please contact customer service for assistance in selecting the correct pump and motor for your needs.**

Specifications:

HP: 1

Discharge:  2"

Speed:  3500 RPM

Cord:  20' SJTOW with NEMA Plug

Body Material:  Cast Iron

Impeller Diameter:  4.25"

Motor:  Single Phase, 230V

Maximum Amps:  5.5

Weight:  65 lbs

Goulds Water Technology AGS Series Axial Grinder Pumps are built to last and are ideal solutions for residential and light commercial applications.

The AGS Series grinder pumps feature axial grinder and semi-open impeller technology to easily slice through the solids, flushables and trash found in the modern wastewater stream without roping or clogging.  The powerful semi-open impeller and axial grinder reduce waste to a fine slurry to minimize downtime and service issues. AGS Series pumps offer solutions for a range of residential and light commercial applications and are an ideal replacement for 2" discharge sewage pumps.

• Semi-open impeller: Powerful, non-clogging, cast iron design. Balanced for smooth operation
• Trusted performance: The proven axial grinder and semi-open impeller technology reduces downtime caused by clogging or roping
• Premium mechanical seal: (Silicon Carbide/Silicon Carbide/BUNA) design provides superior protection against sand and abrasive damage
• Durable construction: One piece, uni-body cast iron casing, and stainless steel motor shaft
• Motor: Oil-cooled/fully submerged in high grade turbine oil for more efficient heat dissipation, permanent lubrication of bearings and mechanical seal, and protection against outside environment

Series Features:

• Design: Capable of grinding domestic sewage in the modern wastewater stream.
• Cutter system: Stainless steel, axial lobe-cutter design with 8-hole cutting plate, capable of 4.9 million bites per hour and TDH up to 120 feet.
• Impeller: Cast Iron semi open 2 vane impeller.
• Casing: Cast iron, volute type for high efficiency. Adaptable for guide rail system.
• Motor: Fully submerged in oil-filled chamber. High grade turbine oil surrounds motor for more efficient heat dissipation, permanent lubrication of bearings and mechanical seal, and protection against outside environment.
• Motor shaft: 300 series stainless steel.
• Designed for continuous operation: Pump ratings are within the motor manufacturer's recommended working limits, can be operated continuously without damage when fully submerged. Tested to UL 778 and CSA 22.2 108 Standards By Canadian Standards Association
• Bearings: Upper and lower single row sealed ball bearings for precision positioning of parts and to carry all radial and thrust loads.
• Mechanical seal: Hardfaced silicon carbide on silicon carbide for longer life, stainless steel metal parts, BUNA-N elastomers.
• Power cable: Severe duty rated, oil and water resistant. Epoxy seal on motor end provides secondary moisture barrier in case of outer jacket damage and to prevent oil wicking.
• O-ring: Assures positive sealing against contaminants and oil leakage.
• Paint: Electro-coat paint process protects all casting surfaces. May be used with optional guide rail. See Fittings or Pump Removal Systems.

Applications:

Designed for residential/light commercial/small office sewage (2” pump replacement and new construction) or anywhere modern wastewater flushables are creating clogging issues.

• 2" sewage pump replacement (.5 hp & 1 hp)
• Residential and small office new construction (wastewater)
• Applications where modern wastewater flushables are creating clogging

Specifications:

• Pump:
  • Capacities: to 53 gpm/12 m³/hr
  • Total heads: to 120 ft/ 36.6m TDH
  • Temperature: Class F insulation - 104ºF (40ºC) maximum continuous, 140ºF (60ºC) maximum intermittent
  • Single mechanical seal: silicon carbide rotary/silicon carbide stationary, 300 series stainless steel metal parts, BUNA-N elastomers
  • Fasteners: 300 series stainless steel
  • Axial cutter and plate: 440C hardened stainless steel

Motors:

• Single-phase motor with on winding thermal protector. No external capacitor kits required.
• Class F insulation
• Shaft: 300 series stainless steel threaded design
• Bearings: Single row sealed ball bearings, upper and lower
• Power cord with a 115V or 230V NEMA three prong grounding plug. Allows connection to a piggyback float switch. 20 foot long cable. 2HP version has bare leads
