Myers QP50B Quick Prime Self-Priming Centrifugal Pump (5 HP, Single Phase, 230V, Brass Impeller)
Myers QP50B Quick Prime Self-Priming Centrifugal Pump (5 HP, Single Phase, 230V, Brass Impeller)
SKU:QP50B
Couldn't load pickup availability
The Pentair Myers QP50B Quick Prime Self-Priming Centrifugal Pump is the preferred option for sprinkler systems, car washes, sump drainage and water transfer and removal. Built with a cast iron case for durability and corrosion resistant impeller for longevity. This 5 HP pump and motor combination has a maximum flow rate of 132 gpm. Designed and manufactured by Myers, a trusted name in the centrifugal pump and motor industry. Please contact a member of our sales or service team for assistance in selecting the correct pump for your needs!
Specifications:
Pump Casing Material: Cast Iron
Voltage: 230V
Motor: 5 HP, Single Phase
Impeller Material: Brass
Ports: 2-1/2" Suction x 2" Discharge NPT
Maximum Flow Rate: 132 gpm - See Performance Chart
Maximum Head: 180'
Shutoff Pressure: 77 psi
Duty Cycle: Continuous
Frequency: 60 Hz
The Quick Prime Self-Priming Centrifugal Pump is designed for demanding jobs where a lot of water is required over a long period of time such as lawn and garden sprinkling, car washing, or other big cleaning/maintenance jobs, it’s built for one purpose only – continuous high performance service. Not for use with corrosive chemicals or flammable liquids.
Features:
- Ruggedly Built: Meets the demands of long, hard continuous service without overloading the motor.
- Manufactured to precise performance specifications.
- Impellers: Corrosion resistant for long life.
- Simple Design: Powerful, efficient operation and easy servicing.
- High tensile gray iron pump case and motor bracket
- Square rubber sealing rings
- Proven thermoset diffuser
- Engineered composite impeller
- Carbon/ceramic shaft seal
Applications:
Lawn and gardening sprinkling, car washing, big cleaning/maintenance jobs, sump drainage, water transfer, or flood control water removal.
